PROCESSOR

CPU

NVT78336

CPU frequency

550MHz

Flash Memory

4M Byte

SDRAM

64M Byte

DVB-T

TUNER

Tuner Type

Rafeal  R836

Frequency Range

174MHZ-860MHZ

Input  impedance

75 Ω

Input Level Range

min -78dbm max -20dbm（64QAM,8K 1/8,7/8）

CHANNEL

DECODING

Standard

DVB-T2

Demodulation

COFDM, 16QAM, 64QAM

Guard Intervals

1/4, 19/256, 1/8, 19/128, 1/16, 1/32, 1/128

Code Rate

1/2, 3/5, 2/3, 3/4, 4/5, 5/6

DEMULTIPLEXER

Standard

ISO/IEC 13818-1

Maximum input code flow

72.8Mbps(Serial)/12.5Mpsbs(in parallel)

VIDEO

DECODING

Video Decode

MPEG4, MPEG4-AVC/H.264 HP @ L4.0, MPEG2 ISO/IEC 13818-2 MP@HL/ML

Aspect ratio

4:3,16:9

Video resolution

1080p/1080i/720p/576p/576i

AUDIO

DECODING

Decoding

MPEG1, MPEG2 ISO/IEC 13818-3

 LAYER I& II ,Dolby (AC3,E-AC3)

Output mode

Left, Right, Stereo, and Reverberation

Sampling frequency

32, 44.1, 48.96KHz

FRONT PANEL

LED Display

4 Digit LED Display

IR receiver

38 KHz

USB Port

USB 2.0 Type A

Buttons

POWER, CH+, CH-,

REAR PANEL

RF IN

IEC 169-2, Male

LOOP OUT

IEC 169-2, Male

USB Port

USB 2.0 Type A

S/PDIF

Digital audio output

AV OUT

1

Power switch

1

CASE & DIMENSIONS

Material

Plastic front panel+ Metal housing

Temperature

-20~50℃

Input Voltage

AC 100～250V, 50Hz/60Hz

Consumption

Max 8W

Humidity

<95%
